Abbott Architect i1000SR Immunoassay System

Contact us with any Questions.

Thank you!

Request Quote



The ARCHITECT i1000SR Immunoassay Analyzer meets your laboratory’s high standards by delivering STAT results when you need them. The advanced technology and flexible protocols built into the ARCHITECT i1000SR enhance laboratory workflow and allow you to report results with confidence. The ARCHITECT i1000SR Immunoassay Analyzer consistently processes a host of STAT protocol assays, regardless of routine workload.

Additional information



Dimensions (HxWxD) 49” x 59” x 30”
124.5 x 149.9 x 76.2 cm
Weight 636 lb
288 kg
Maximum Throughput Up to 100 tests/hour
Sample Types Serum, Plasma, Whole Blood, Urine
Sample Tubes Height: 72-102 mm
Diameter: 9.6 -16.1 mm
Sample Cup Yes (50 µL dead volume)
Sample Capacity 65
Sample Barcode Types Code 39, Codabar, Interleaved 2 of 5, Code 128
Sample Result Storage 50,000
Sample Volume 10-150 μL, Average: 50 µL
Automatic Dilution Yes
Sample Probe Carryover <0.1 parts per million
Reagent Capacity 25 refrigerated positions
Reagent Type 100% liquid ready-to-use liquid reagents

Test Menu

Cancer Cardiac Fertility/Pregnancy Infectious Disease
CA 125 CK-MB Estradiol Anti-HAV IgM
CA 15-3 Myoglobin FSH Anti-HBc
CA 19-9 XR Troponin-I hCG (Total B-hCG) Anti-HBc IgM
CEA Galectin-3IN DVLMT LH Anti-HBs
Free PSA High Sensitive Troponin-I Progesterone Anti-HCV
HE-4 Prolactin HBsAg
Total PSA SHBG HBsAg Confirmatory
Testosterone HIV Ag/Ab Combo
Metabolic Therapeutic Drug Monitoring Transplant Thyroid
Active-B12 (HoloTC) Carbamazepine Cyclosporine Anti-Tg
B12 Digoxin Sirolimus Anti-TPO
C-Peptide Gentamicin Tacrolimus Free T3
Cortisol Phenobarbital Free T4
Ferritin Phenytoin T-Uptake
Folate Theophylline Total T3
Hemoglobin A1c (Whole Blood) Valproic Acid Total T4
Homocysteine Vancomycin TSH
Intact PTH
Vitamin D
