Awareness Technology Stat fax 4500 Chemistry Analyzer

Awareness Technology Stat fax 4500 Chemistry Analyzer

Includes:

This system includes an Interactive touch-screen LCD with USB mouse option, USB Connection to PC with SF Capture software, accommodates 12mm tubes or cuvettes, Flow cell, Bichromatic and Monochromatic reading, six filters (340-700nm). Includes on board curve fitting calculations with step-by-step user prompting Absorbance, Factor, Standard, Point-to-Point, Regression, and Cubic Spline. Built-in 37°C incubation block with 12 stations, Large non-volatile memory storing 140 user-entered tests, and built-in printer to meet the requirements of modern laboratories.

Features:

The Stat Fax 4500 Chemistry Analyzer is a space-saving standalone system designed to meet the demands of modern laboratories to perform a wide range of diagnostic tests on biological samples efficiently. It features a built-in printer, a 12-station incubation block, and an interactive touchscreen interface for rapid results in approximately 3 seconds per tube. The Stat Fax supports various calculation modes, including single or multipoint calibration, kinetic rates and turbidimetric assays commonly used for routine chemistry, all including step-by-step user prompting to simplify use.

To further enhance efficiency, The Stat Fax 4500 utilizes brilliant bichromatic optics with Ion Assisted Deposition (IAD) hard coat filters, which provide superior durability and photometric accuracy by resisting humidity and temperature-related wear. The standard model wavelength range includes six filters (340 ,405, 505, 545, 580, and 630 nm), with alternate filters available from 340-700 nm.

The Stat Fax 4500 can be customized to simplify user interface and navigation with the use of a Capacitive Touchscreen, Icon-Driven Menu, Multilingual Support, and a Mouse and External Computer option if preferred. The Stat Fax 4500 is a powerful system, designed to make diagnostic tests efficient and quick.

Key Features:

6 Long-life IAD filters (340-700nm)

Accommodates 12mm tubes or cuvettes

Interactive touch-screen LCD with USB mouse option

Read cell that is temperature controlled to 37°C

Bichromatic and Monochromatic reading

Turbidimetric assay capability

On board curve fitting calculations with step-by-step user prompting

Single point calibration by standard or factor and multipoint calibration, kinetic rate by standard or factor (batch or singly)
